PROTECT-PE-11-SK Schmersal Electronic Components

Product Details

• Removable Terminals
  Yes
• Number of auxiliary contacts
  2, 9
• Height
  126 mm
• Ambient temperature, minimum
  -25 °C
• Rated control voltage at AC 50 Hz, maximum
  26.4 VAC
• Input resistance at Ue
  2,900 Ω
• Voltage, Utilisation category DC12
  24 VDC
• Switching capacity, maximum
  24 VDC
• Climatic stress
  EN 60068-2-78
• Number of openers
  1
• Degree of protection of the enclosure
  IP20
• Storage and transport temperature, maximum
  +85 °C
• Overvoltage category
  III
• Voltage, Utilisation category DC13
  24 VDC
• Conduction resistance, maximum
  40 Ω
• Short-circuit recognition
  Yes
• Earth connection detection
  Yes
• Mechanical life, minimum
  10,000,000 Operations
• Width
  65.5 mm
• Rated control voltage at AC 60 Hz, maximum
  26.4 VAC
Ambient temperature, maximum
+55 °C
Drop-out delay in case of power failure, maximum
60 ms
Switching capacity, minimum
10 mA
Current, Utilisation category DC12
0.1 A
Electronic Fuse
Yes
Automatic reset function
Yes
Number of signalling outputs
7
Depth
61 mm
Storage and transport temperature, minimum
-40 °C
Rated AC voltage for controls, 50 Hz, minimum
21.1 VAC
Pull-in delay at automatic start, maximum, typically
10 ms
Input signal, HIGH Signal 1
19 - 28,8 VDC
Stop-Category
0
Wire breakage detection
Yes
Mounting
Snaps onto standard DIN rail to EN 60715
Cable section, minimum
0.14 mm²
Restistance to shock
30 g / 11 ms
Electrical power consumption
1.7 W
Rated AC voltage for controls at DC minimum
21.1 VDC
EMC rating
EMC-Directive
Gross weight
160 g
Number of shutters
1
Terminal Connector
Screw connection, plug-in
Rated impulse withstand voltage Uimp
4 kV
Degree of protection of the mounting space
IP20
Rated AC voltage for controls, 60 Hz, minimum
21.1 VAC
Note (Contact resistance)
in new state
Input signal, LOW Signal 0
0 - 1 VDC
Standards
IEC 61508, IEC/EN 60204-1, EN 60947-5-1
Number of LEDs
6
Cable section, maximum
1.5 mm²
Degree of protection of clips or terminals
IP20
Degree of pollution to VDE 0110
2
Rated control voltage at DC, maximum
28.8 VDC
Current, Utilisation category DC13
2 A
Drop-out delay in case of emergency stop, maximum
10 ms
Enclosure material
Glass-fibre reinforced thermoplastic, ventilated
Integral System Diagnostics, general
Yes
Terminal designations
IEC/EN 60947-1
Tightening torque of Clips
0.6 Nm
Resistance to vibrations to EN 60068-2-6
10...55 Hz, Amplitude 0.35 mm, ± 15 %
Rated operating voltage
24 VDC -15% / +20%, residual ripple max. 10 %
Contact resistance, maximum
0.1 Ω
