EX-TS 335-11Z-3G/D Schmersal Electronic Components

Product Details

• Actuating force, minimum
  17 N
• Terminal Connector
  Screw connection
• Note (Cable section)
  All indications about the cable section are including the conductor ferrules.
• Actuator type to DIN EN 50041
  B
• Number of auxiliary contacts
  1
• Gross weight
  256 g
• Cable cross-section of the cable glands, maximum
  12 mm
• Height of sensor
  103.5 mm
• Utilisation category AC-15
  4 A
• Material of the contacts, electrical
  Silver
• Enclosure material
  Aluminium
• Cable section, minimum
  0.75 mm²
• Degree of protection
  IP67
• Safety functions
  Yes
• Enclosure coating material
  painted
• Wire cross-section
  13 AWG
• Thermal test current
  10 A
• Switching frequency
  5,000 /h
• Number of safety contacts
  1
• Actuating speed, maximum
  0.5 m/s
Length of sensor
38 mm
Rated insulation voltage Ui
500 V
Switching principle
Slow action
Housing construction form
Norm construction design
Impact energy, maximum
4 J
Width of sensor
40.5 mm
Rated impulse withstand voltage Uimp
6 kV
Bounce duration, maximum
2 ms
Actuating element
Plunger
Cable cross-section of the cable glands, minimum
7 mm
Ambient temperature, minimum
-20 °C
Switching element
NO contact, NC contact
Mechanical life, minimum
30,000,000 Operations
Note (Switchover time)
Switchover time in accordance with actuating speed
Cable section, maximum
2.5 mm²
Ambient temperature, maximum
+60 °C
Utilisation category DC-13
1 A
