40009ET3G588/9-W22 WEG AC Motors
Product Details
- Number of Poles 8 Pole
- Voltage 460 V
- Output Rating 400 HP
- Rated Speed 894 rpm
- Flange Type Without
- Output 400 HP (300 kW)
- Frame 588/9T
- Temperature rise 80 K
- Number of Poles 8
- Locked rotor torque 200 %
- No load current 240 A
- Degree of Protection IP55
- Number of poles 8
- Synchronous speed 900 rpm
- Locked rotor time 45s (cold) 25s (hot)
- Duty Cycle Cont.(S1)
- Starting Method Direct On Line
- Flange Without
- Slip 0.67 %
- Rated voltage 460 V
- Ambient temperature -20°C to +40°C
- Mounting F-1
- Voltage 460 V
- Output rating 400 HP
- Enclosure IC411 - TEFC
- Breakdown torque 250 %
- Standard NEMA MG-1
- Rated speed 894 rpm
- LRC 7.2x(Code J)
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Frequency 60 Hz
- Rated torque 2350 ft.lb
- Moment of inertia (J) 537 sq.ft.lb
- Approx. weight³ 5072 lb
- Rated current 498 A
- L. R. Amperes 3586 A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
40009ET3G588/9-W22 Related Documents
Manufacturer warranty
40009ET3G588/9-W22 WEG
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
About the manufacturer
Applied Automation is an authorized WEG distributor, proud to partner with this globally recognized leader in industrial products and solutions. WEG stands out as a manufacturer committed to innovation, sustainability, and technological excellence, offering a vast portfolio of products that cater to diverse industrial needs. With a strong emphasis on energy efficiency and performance, WEG's produc...
Recently viewed products
Relevant products
FAQ
Out if stock but available for backorder.
W22 NEMA Premium Efficiency 400 HP 8P 588/9T 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted
