BNS 260-02Z-L 5,0M Schmersal Electronic Components

Product Details

• Coding level according to ISO 14119
  Low
• Actuating element
  Magnet
• Length of cable
  5 m
• Ambient temperature, maximum
  +70 °C
• Switching frequency, maximum
  5 Hz
• Number of openers
  2
• Gross weight
  226.8 g
• Terminal Connector
  Cable
• Storage and transport temperature, maximum
  +70 °C
• Number of safety contacts
  2
• Ensured switch distance ON Sao
  5 mm
• Length of sensor
  13 mm
• Restistance to shock
  30 g / 11 ms
• Standards
  IEC 60947-5-3, BG-GS-ET-14
• Notice (Switch distance Sn)
  Axial misalignment, a horizontal and vertical misalignment of the safety sensor and the actuator are tolerated. The possible misalignment depends on the distance of the active surfaces of the sensor and the actuator. The sensor remains active within the t
• Storage and transport temperature, minimum
  -25 °C
• Enclosure material
  Glass-fibre, reinforced thermoplastic
• Wire cross-section
  0.25 mm2
• Resistance to vibrations to EN 60068-2-6
  10 … 55 Hz, amplitude 1 mm
• Installation conditions (mechanical)
  quasi-flush
Ensured switch distance OFF Sar
15 mm
Height of sensor
36 mm
Switching capacity, maximum
10 VA
Number of cable wires
4
Direction of motion
Head-on to the active surface
Width of sensor
26 mm
Degree of protection
IP67
Switching current, maximum
0.4 A
Active principle
Magnetic drive
Material of the Cable mantle
PVC
Ambient temperature, minimum
-25 °C
