100036WT3X5010-W60MV2 WEG AC Motors
Product Details
- Rated current 225/129 A
- Locked rotor time 12s (cold) 7s (hot)
- Noise level² 85.0 dB(A)
- Flange Without
- Frequency 60 Hz
- Service factor 1.00
- Synchronous speed 3600 rpm
- Rated speed 3565 rpm
- Locked rotor torque 60 %
- Ambient temperature 0°C to +40°C
- Number of poles 2
- Slip 0.97 %
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Number of Poles 2
- Moment of inertia (J) 94.0 sq.ft.lb
- Degree of Protection IP24
- Output 1000 HP (750 kW)
- No load current 41.7/24.3 A
- Mounting F-1
- Standard NEMA MG-1
- Rated voltage 2300/4000 V
- Starting Method VFD
- Approx. weight³ 5072 lb
- L. R. Amperes 1463/839 A
- Rated torque 1470 ft.lb
- Duty Cycle Cont.(S1)
- Voltage 2300/4000 V
- LRC 6.5x(Code G)
- Temperature rise 105 K
- Output rating 1000 HP
- Frame 5010/11
- Breakdown torque 200 %
- Rotation¹ CCW
- Terminal box¹ Left position
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
