TV10S 335-03Z Schmersal Electronic Components
Part#:TV10S 335-03Z
Alt. Part#:101179253
Manufacturer:Schmersal
Category:Electronic Components
Product Lifecycle:Active
Product description
Safety switch for hinged guards; Hinge safety switch; 1 Cable entry M 20 x 1.5; Metal enclosure; Good resistance to oil and petroleum spirit; Actuator heads can be repositioned by 4 x 90°; 40,5 mm x 107 mm x 65,3 mm; Actuator shaft can be turned 360°
Product Details
- Mounting hole for the Shaft 10 mm
- Cable section, minimum 0.75 mm²
- Ambient temperature, maximum +70 °C
- Switching element Opener (NC)
- Positive break angle 7 °
- Terminal Connector Screw connection
- Width of sensor 40.5 mm
- Utilisation category DC-13 4 A
- Actuating element Other
- Mechanical life, minimum 1,000,000 Operations
- Ambient temperature, minimum -25 °C
- Number of safety contacts 3
- Length of sensor 65.3 mm
- Rated insulation voltage Ui 500 V
- Gross weight 253 g
- Cable section, maximum 2.5 mm²
- Rated impulse withstand voltage Uimp 6 kV
- Height of sensor 107 mm
- Positive break torque 0.6 Nm
- Switching principle Creep circuit element
- Enclosure material Aluminium
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Thermal test current 10 A
- Enclosure coating material painted
- Material of the contacts, electrical Silver
- Degree of protection IP67
- Switching frequency 1,000 /h
- Utilisation category AC-15 4 A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
