7000-40041-0150400 Murr Elektronik Cable Assemblies

Product Details

• Series
  Connector Systems
• Form
  40041
• Compression gland
  M12 (SW13)
• Cable identification
  015
• Construction (core)
  19× 0.15 mm (multi-strand wire class 5)
• Outer-Ø (jacket)
  5.2 mm ±5%
• Bend radius (moving)
  10× outer Ø
• Material
  PUR
• Cable weight [g/m]
  48,4 g
• Material (wire isolation)
  PVC
• chemical resistance
  good resistance to oil, gasoline and chemicals
• Cable length
  4 m
• Locking of ports
  Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
• Pollution Degree
  3
• Material property (wire isolation)
  CFC-, cadmium-, silicone- and lead-free
• Color (jacket)
  yellow
• Bend radius (fixed)
  5× outer Ø
• Protection
  IP65, IP66K, IP67 inserted and tightened (EN 60529)
• No./diameter of wires
  5× 0.34 mm²
• AWG
  similar to AWG 22
Shore hardness (jacket)
85 ±5 A
Current load capacity
to DIN VDE 0298-4
Operating current per contact
max. 4 A
Outer Ø
5.2 mm ±5%
Diameter (core)
5× 0.34 mm²
Material (jacket)
PVC
Temperature range (fixed)
-30...+80 °C
Operating voltage (only UL listed)
max. 30 V AC/DC
suitable for corrugated tube (internal Ø)
10 mm
Cable Type
1 (PVC)
Shield
no
Jacket Color
yellow
Operating voltage
max. 125 V AC/DC
Wire isolation
PVC (br, wh, bl, bk, gnye)
Material (wire)
Cu wire, bare
Wire-Ø incl. isolation
1.25 mm ±5%
thermal resistance
flame retardant UL 1581 VW1 / CSA FT1
Material group
IEC 60664-1, category I
Temperature range
-25...+85 °C, depending on cable quality
Single wire Ø (core)
0.15 mm
Color/numbering of wires
br, bk, bl, wh, gnye longitudinally striped
Test voltage
2000 V AC
Rated surge voltage
1.5 kV
Locking material
Zinc die casting, matte nickel plated
Approval (cable)
UL (AWM-Style 2464/1731), CSA
Stranding combination
5 wires twisted around central filler
Nominal voltage
UL 300 V AC
Temperature range (mobile)
-5...+80 °C
Coding
A-coded
Standards
DIN EN 61076-2-101 (M12)
Resistor (core)
max. 60 Ω/km (20 °C)
Shore hardness (wire isolation)
45 ±5 D
Material property (jacket)
CFC-, cadmium-, silicone- and lead-free
Product article number of manufacturer
7000-40041-0150400
