TK 461-03Y Schmersal Electronic Components

Product Details

• Active principle
  mechanical
• Actuating angle, from left of switch axis
  45 °
• Actuating speed, minimum
  1 mm/min
• Gross weight
  1,990 g
• Slide form
  Castor
• Note (Cable section)
  All indications about the cable section are including the conductor ferrules.
• Height of sensor
  229 mm
• Switching principle
  Creep circuit element
• Material of the contacts, electrical
  Silver
• Actuating element
  Offset roller lever
• Note (Actuating speed)
  Actuating speed with vertical actuating angle to switch axis
• Degree of protection
  IP65 to EN 60529
• Enclosure coating material
  painted
• Actuating angle, from right of switch axis
  30 °
• Wire cross-section
  13 AWG
• Enclosure material
  Grey cast iron, galvanised
• Mechanical life, minimum
  10,000,000 Operations
• Cable section, minimum
  1.5 mm²
• Number of openers
  3
• Actuating speed, maximum
  0.5 m/s
Cable section, maximum
2.5 mm²
Rated impulse withstand voltage Uimp
6 kV
Ambient temperature, maximum
+90 °C
Roller material
Plastic
Terminal Connector
Screw connection
Length of sensor
64 mm
Switching element
Opener (NC)
Contact opening
max. 2 x 6 mm
Standards
EN 60947-5-1
Width of sensor
118 mm
Diameter of Castor
25 mm
Width of Castor
6.5 mm
Ambient temperature, minimum
-30 °C
Thermal test current
16 A
Rated insulation voltage Ui
400 V
Utilisation category AC-15
4 A
Note (Switching element)
with double break
