D1614B1020W ROSS Controls Electronic Components
Part#:D1614B1020W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
16 Series, 3/2-Way, Single Solenoid Valve, Normally Open, Port (In) G1/4", Port (Out) G1/4", 24 VDC
Product Details
- Actuation Electrical
- Mounting Inline
- Length (mm) 66
- Default Position Normally Open
- Power Consumption 14 watts
- Height (mm) 95
- Valve Type Directional Control
- Avg Cv 0.3
- Fluid Media Filtered air
- Valve Body Material Cast Aluminum
- Return Spring
- Media Temperature (Celcius) 4 to 80
- Width (mm) 73
- Thread Type G
- Application General
- Duty Rating Continuous Duty
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Operating Pressure (bar) 0.3 to 10
- Weight (kg) 0.6
- Series 16
- Voltage 24 VDC
- Height 3.73 in (95 mm)
- Outlet Pipe Size 1/4"
- Construction Poppet
- Weight 1.4 lb (0.6 kg)
- Inlet Pipe Size 1/4"
- Manual Override Non-locking
- Ambient Temperature (Celcius) 4 to 50
- Width 2.88 in (73 mm)
- Exhaust Pipe Size 1/4"
- Function 3/2 Single Solenoid
- Media Temperature 40 to 175 F (4 to 80 C)
- Length 2.58 in (66 mm)
- Seal Material Buna-N
- Connection Hardwired
- Operating Pressure 5 to 150 psig (0.3 to 10 bar)
- Poppet/Spool Material Acetal
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of D1614B1020W on Applied Automation is $266.00. Order now.
