7700-40101-U030030 Murr Elektronik Cable Assemblies

Product Details

• Weight
  33 g
• Series
  Connector Systems
• Mounting method
  inserted, tightened
• Construction (core)
  19× 0.16 mm (multi-strand wire class 5)
• Stranding combination
  3 wires twisted
• Nominal voltage
  300 V AC
• Approval (cable)
  UL (AWM-Style 20626/1731), CSA; CE conform
• Color/numbering of wires
  br, bk, bl
• chemical resistance
  good resistance to oil, gasoline and chemicals
• Form
  40101
• Single wire Ø (core)
  0.16 mm
• Outer-Ø (jacket)
  4.9 mm ±5%
• Product article number of manufacturer
  7700-40101-U030030
• Cable identification
  U03
• Resistor (core)
  max. 46.9 Ω/km (20 °C)
• Current load capacity
  to DIN VDE 0298-4
• Cable length
  0,3 m
• Cable weight [g/m]
  35,97 g
• Jacket Color
  yellow
• Temperature range (fixed)
  -40...+105 °C
Material group
IEC 60664-1, category I
Wire-Ø incl. isolation
1.27m ±5%
Test voltage
2000 V AC
Torsion stress
±180°/m
Operating voltage
max. 250 V AC/DC
Diameter (core)
1× 3× AWG22/19 (0.382)
Color (jacket)
yellow
Bend radius (moving)
10× outer Ø
Pollution Degree
3
Material (wire)
Cu wire, bare
thermal resistance
flame retardant
No. of bending cycles (C-track)
max. 10 Mio. (25 °C)
Rated surge voltage
2.5 kV
Material (jacket)
TPE
Bend radius (fixed)
5× outer Ø
Temperature range
-25...+85 °C, depending on cable quality
Material (wire isolation)
semi-rigid PVC
Temperature range (mobile)
-20...+90 °C
