E210A-1E024 Clippard Electronic Components

E210A-1E024 on Applied Automation
Clippard

Part#:E210A-1E024

Manufacturer:Clippard

Category:Electronic Components

Product Lifecycle:Active

Product description

10 mm N-C 2-way Valve, 90°, 0.020", 0.6W, 24 VDC

Product Details

  • Max. Flow
    13 l/min @ 100 psig
  • Operating Pressure
    0 to 100 psig (7 bar)
  • Function
    2-Way Normally-Closed
  • Operating Temperature Range
    14 to 122°F (-10 to 50°C) When below 32°F, must use clean, dry air.
  • Manifolds
    10 mm Manifolds
  • Wattage
    0.6 Watts
  • Materials
    Stainless steel core and springs, nylon body, FKM dynamic seals, and Nitrile gasket and static seals. FKM gasket and static seals available.
  • Length
    1.08
  • Voltage
    24 VDC
  • Connector Wire
    Molex #28139 plug with terminal insert #50212-8000
  • Response Time
    10 ms nominal
  • Connection
    90°
  • Mount
    2 M1.7 screws
  • Accessories
    Connector with cable: C2A-RB300 (30 cm), C2A-RB500 (50 cm), C2A-RB1000 (1 m)
  • Weight
    0.0250
  • Medium
    Air, Water, Gas or Compatible Fluids
  • Coil Insulation Class
    F 311°F (155°C)
  • Voltage Operating Range
    ±10%

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of E210A-1E024 on Applied Automation is $24.82. Order now.

E210A-1E024 Related Documents

2DManifoldFiles.pdf2DValvesDrawings.pdf

Manufacturer warranty

E210A-1E024 Clippard

$24.82

Your price can be lower.
Log in or Create account to check your discount

This part can be ordered

Select Qty:

$24.82

$24.82 each

This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
