DV-3M-24 Clippard Pneumatic Components

Name: DV-3M-24
Brand: Clippard
Price: 70.12 USD
Availability: InStock

Part#:DV-3M-24

Manufacturer:Clippard

Category:Pneumatic Components

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Oct 22, 2026

Product description

DV 3-Way Valve, Wire Leads, Manifold Mount, 24 VDC, Manifold Options: 15781-2, 15781-4, 15490-5

Product Details

Function
3-Way Fully-Ported, Universal
Wattage
1.9 Watts
Operating Temperature Range
32 to 130°F (0 to 55°C) at continuous duty
Response Time
10 to 15 milliseconds
Connection
Wire Leads, 18"
Flow Rate
70 l/min @ 100 psig/7 bar
Ports
1/8" NPT
Operating Pressure
95 to 125% of Rated Voltage
Material, Wetted
PPS, PEI, Stainless Steel
2D Files
2D Files
Material, Seals
Nitrile
Weight
0.1500
Medium
Compatible Fluids (40 micron filter recommended)
Voltage
24 VDC
Mount
Manifold
Unit
Imperial

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of DV-3M-24 on Applied Automation is $70.12. Order now.

DV-3M-24 Related Documents

DataSheet.pdf

$70.12

Your price can be lower.
Log in or Create account to check your discount

Stock:

Select Qty:

$70.12

$70.12 each

Fast Shipping & Delivery

We deliver nationwide and international

Secure Payment Processing

Your Safety, Our Priority.

Warranty

Manufacturer warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us
