7000-40901-0160300 Murr Elektronik Cable Assemblies

Product Details

• Weight
  215 g
• Series
  Connector Systems
• Switch off peak
  max. 55 V
• Material
  MSUD (PBT); M12 (PUR)
• Cable Type
  1 (PVC)
• Diameter (core)
  3× 0.75 mm²
• Material property (jacket)
  CFC-, cadmium-, silicone- and lead-free
• Nominal voltage
  300/500 V AC
• Locking of ports
  M3/M12×1 mm (recommended torque 0.4/0.6 Nm)
• Temperature range
  -25...+85 °C, depending on cable quality
• Wire-Ø incl. isolation
  1.8 mm ±5%
• Material (wire isolation)
  PVC
• Bend radius (fixed)
  5× outer Ø
• Form
  40901
• Material (gasket)
  PUR
• Housing
  Black plastic (gray on request)
• Shore hardness (wire isolation)
  43 ±5 D
• Material (jacket)
  PVC
• Temperature range (fixed)
  -30...+70 °C
• Current consumption
  approx. 15 mA
Compression gland
M12 (SW13)
Pollution Degree
3
Resistor (core)
max. 26 Ω/km (20 °C)
Outer-Ø (jacket)
5.9 mm ±5%
Product article number of manufacturer
7000-40901-0160300
Operating current per contact
max. 4 A
Additional suppressor
Diode/Z-Diode
Cable weight [g/m]
63,8 g
Material property (wire isolation)
CFC-, cadmium-, silicone- and lead-free
Shield
no
Cable length
3 m
Material group
IEC 60664-1, category I
suitable for corrugated tube (internal Ø)
10 mm
Color/numbering of wires
bk numbered, gnye longitudinally striped
Shore hardness (jacket)
80 ±5 A
Bend radius (moving)
10× outer Ø
Protection
IP67 inserted and tightened (EN 60529)
Switch off delay time
max. 20 ms
Single wire Ø (core)
0.2 mm
AWG
similar to AWG 18
Temperature range (mobile)
-5...+70 °C
Operating voltage
24 V AC ±20% / DC ±25%
Approval (cable)
CE conform
Stranding combination
3 wires twisted
Color (jacket)
yellow
Rated surge voltage
0.8 kV
Cable identification
016
chemical resistance
good resistance to oil, gasoline and chemicals
LED display
yellow
Locking material
Zinc die casting, matte nickel plated
Material (wire)
Cu wire, bare
Construction (core)
24× 0.2 mm (multi-strand wire class 5)
Test voltage
3000 V AC
Current load capacity
to DIN VDE 0298-4
