RSS32S2 Schmersal Key Switches

Product Details

• Colour of the front ring
  Silver
• Mounting
  Mounting flange EFM
• Diameter total
  39.5 mm
• Ambient temperature, minimum
  +0 °C
• Material of the front ring
  Aluminium
• Versions
  Key - Selector switch - Front plate mounting
• Mechanical life, minimum
  300,000 Operations
• Height with key inserted
  58 mm
• Colour of the cylinder lock
  Silver
• Fully insulated
  Yes
• diameters for the cylinder lock
  22 mm
• Restistance to shock
  50 g
• Gross weight
  100 g
• Unlocking
  Rotating unlatcher
• Diameter of the front ring
  39.5 mm
• Spacing
  50 x 60 mm
• Sealing type
  Membrane, Lip gaskets, Form seals
• Latching position
  right, left
• Thickness, of the front panel, minimum
  1 mm
• Material of the cylinder lock
  Steel
Key withdrawal position
Position 0
Diameter hole, with tolerance indication
22.3 + 0.4 mm
Ambient temperature, maximum
+75 °C
Latching
Yes
Switching angle, right
90 °
Diameter hole
22.3 mm
Installation conditions (mechanical)
arbitrarily
Number of plunger
2
Switching angle, left
90 °
Thickness of the front panel, maximum
6 mm
Standards
EN 60947-5-1, IEC/EN 60947-1
Number of switch positions
3
Tightening torque of the screw
0.6 Nm
Degree of protection
IP65
