W6456B4412 ROSS Controls Electronic Components
Part#:W6456B4412
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
ISO 5599-1 Valve, Size 3, W64 Series, 5/2 Single, Pressure Controlled, Poppet, High Temp
Product Details
- Pilot Type External
- Application High Temperature
- Poppet/Spool Material Aluminum & Stainless Steel
- Weight (kg) 1.1
- Fluid Media Filtered Air
- Ambient Temperature (Celsius) 4 to 105
- Width (mm) 163
- Default Position Normally Open
- Media Temperature (Celsius) 4 to 105
- Width 6.4 in (163 mm)
- Valve Type Directional Control
- Media Temperature 40 to 220 F (4 to 105 C)
- Height 2.3 in (59 mm)
- Return Spring
- Ambient Temperature 40 to 220 F (4 to 105 C)
- Length (mm) 65
- Valve Standard ISO 5599-1
- Construction Poppet
- Operating Pressure (bar) 2 to 10
- Avg. Cv 4.0
- Function 5/2 Single Pilot
- Valve Body Material Bar Stock Aluminum
- Length 2.6 in (65 mm)
- Series W64
- Size 3
- Actuation Pneumatic
- Operating Pressure 30 to 150 psig (2 to 10 bar)
- Weight 2.3 lb (1.1 kg)
- Mounting Base Mount
- Pilot Supply Minimum Must be ≥ inlet pressure
- Seal Material Fluorocarbon
- Height (mm) 59
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of W6456B4412 on Applied Automation is $242.50. Order now.
W6456B4412 Related Documents
Manufacturer warranty
W6456B4412 ROSS Controls
$242.50
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$242.50
$242.50 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Recently viewed products
Relevant products
FAQ
What is the price of W6456B4412?
Purchase the W6456B4412 from Applied Automation at the price of $242.50. Order today.
Out if stock but available for backorder.
ISO 5599-1 Valve, Size 3, W64 Series, 5/2 Single, Pressure Controlled, Poppet, High Temp
