7999-08121-6330300 Murr Elektronik Cable Assemblies

Product Details

• Weight
  98 g
• Series
  Connector Systems
• Approval (cable)
  cURus (AWM-Style 20549/10493); CE conform
• Single wire Ø (core)
  0.1 mm
• Outer-Ø (jacket)
  4.1 mm ±5%
• Bend radius (moving)
  10× outer Ø
• Cable identification
  633
• Diameter (core)
  3× 0.34 mm²
• Color (jacket)
  black
• No. of bending cycles (C-track)
  max. 10 Mio. (25 °C)
• Operating voltage
  24 V DC ±25%
• Material (wire)
  Cu wire, bare
• Material (jacket)
  PUR
• Temperature range (fixed)
  -40...+80 °C, (+90 °C at max. 10 000 operating hours)
• Acceleration (C-track)
  max. 10 m/s²
• Locking of ports
  Screw thread (M8×1 mm) recommended torque 0.4 Nm, self-securing
• Material property (wire isolation)
  CFC-, halogen-, cadmium-, silicone- and lead-free
• chemical resistance
  good resistance to oil, gasoline and chemicals (EN 60811-404)
• Nominal voltage
  300 V AC
• Cable length
  3 m
Protection
IP66K, IP67 inserted and tightened (EN 60529)
Construction (core)
42× 0.1 mm (multi-strand wire class 6)
Color/numbering of wires
br, bk, bl
Material property (jacket)
CFC-, halogen-, cadmium-, silicone- and lead-free, matt, low-adhesion, machine easy to process, abrasion-resistant, hydrolysis and microbial resistant
Travel speed (C-track)
max. 3 m/s
Locking material
Zinc die casting, nickel-plated
AWG
similar to AWG 22
Shore hardness (jacket)
90 ±5 A
Temperature range (mobile)
-25...+80 °C, (+90 °C at max. 10 000 operating hours)
Form
08121
Wire-Ø incl. isolation
1.25 mm ±5%
Bend radius (fixed)
5× outer Ø
Product article number of manufacturer
7999-08121-6330300
Cable weight [g/m]
29,7 g
Material (wire isolation)
PP
thermal resistance
flame retardand UL 1581 Section 1090 (H), CSA FT2 / IEC 60332-2-2
Torsion speed
35 cycles/min
No. of torsion cycles
max. 2 Mio. (25 °C)
Operating current per contact
max. 4 A
Resistor (core)
max. 57 Ω/km (20 °C)
Stranding combination
3 wires twisted
Test voltage
2500 V AC
Torsion stress
±180°/m
Cable Type
3 (PUR)
Shore hardness (wire isolation)
70 ±5 D
Shield
no
Current load capacity
to DIN VDE 0298-4
