7700-48021-U2H0200 Murr Elektronik Cable Assemblies

Product Details

• Weight
  168 g
• Series
  Connector Systems
• Coding
  A-coded
• Cable identification
  U2H
• Material (wire isolation)
  semi-rigid PVC
• Stranding combination
  8 wires twisted around central filler
• thermal resistance
  flame retardant
• Form
  48021
• Compression gland
  M12 (SW13)
• Color/numbering of wires
  br, wh, rd, bl, pk, gr, ye, gn
• Current load capacity
  to DIN VDE 0298-4
• Product article number of manufacturer
  7700-48021-U2H0200
• Material
  PUR
• Wire-Ø incl. isolation
  1.27m ±5%
• chemical resistance
  good resistance to oil, gasoline and chemicals
• No. of bending cycles (C-track)
  max. 10 Mio. (25 °C)
• Rated surge voltage
  0.8 kV
• suitable for corrugated tube (internal Ø)
  without
• Single wire Ø (core)
  0.16 mm
• Bend radius (fixed)
  5× outer Ø
Material group
IEC 60664-1, category I
Pollution Degree
3
Approval (cable)
UL (AWM-Style 20626/1731), CSA; CE conform
Diameter (core)
1× 8× AWG22/19 (0.382)
Outer-Ø (jacket)
6.7 mm ±5%
Torsion stress
±180°/m
Protection
IP65 and IP67 when plugged and screwed down (EN 60529)
Standards
DIN EN 61076-2-101 (M12)
Test voltage
2000 V AC
Operating voltage (only UL listed)
max. 30 V AC/DC
Temperature range
-25...+85 °C, depending on cable quality
Construction (core)
19× 0.16 mm (multi-strand wire class 5)
Jacket Color
gray
Bend radius (moving)
10× outer Ø
Locking of ports
Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
Mounting method
inserted, tightened
Resistor (core)
max. 46.9 Ω/km (20 °C)
Temperature range (fixed)
-40...+105 °C
Cable length
2 m
Operating voltage
max. 30 V AC/DC
Material (wire)
Cu wire, bare
Material (jacket)
TPE
Nominal voltage
300 V AC
Operating current per contact
max. 2 A
Locking material
Zinc die casting, matte nickel plated
Cable weight [g/m]
70,4 g
Color (jacket)
gray
Temperature range (mobile)
-20...+90 °C
