TS 335-12ZUE Schmersal Electronic Components

Product Details

• Number of safety contacts
  2
• Length of sensor
  38 mm
• Cable section, maximum
  2.5 mm²
• Switching principle
  Slow action with overlapping contacts
• Safety functions
  Yes
• Note (Cable section)
  All indications about the cable section are including the conductor ferrules.
• Rated insulation voltage Ui
  500 V
• Gross weight
  190 g
• Note (Switchover time)
  Switchover time in accordance with actuating speed
• Ambient temperature, maximum
  +80 °C
• Switching element
  NO contact, NC contact
• Actuating element
  Plunger
• Mechanical life, minimum
  30,000,000 Operations
• Ambient temperature, minimum
  -30 °C
• Required rated short-circuit current to EN 60947-5-1
  1,000 A
• Switching frequency
  5,000 /h
• Housing construction form
  Norm construction design
• Actuating force, minimum
  17 N
• Height of sensor
  103.5 mm
• Utilisation category AC-15
  230 VAC
Actuator type to DIN EN 50041
B
Terminal Connector
Screw connection
Width of sensor
40.5 mm
Material of the contacts, electrical
Silver
Number of auxiliary contacts
1
Utilisation category DC-13
4 A
Cable section, minimum
0.75 mm²
Thermal test current
10 A
Actuating speed, maximum
0.5 m/s
Rated impulse withstand voltage Uimp
4 kV
Enclosure coating material
painted
Bounce duration, maximum
2 ms
