AZM150SK-11/02RIT-024-B6L Schmersal Safety Switches

Product Details

• Gross weight
  637.6 g
• positive break travel
  10 mm
• Ambient temperature, maximum
  +55 °C
• Length of sensor
  64 mm
• Utilisation category DC-13
  24 VDC
• Power to unlock
  Yes
• Clamping force in accordance with ISO14119 Fzh
  1,500 N
• Cable entry
  3 x M20 x 1,5
• Width of sensor
  40 mm
• Rated insulation voltage Ui
  300 V
• Switching element
  NC contact, NO contact
• Coding level according to ISO 14119
  High
• Clamping force, maximum Fmax
  1,950 N
• Cable section, minimum
  1 x 0.25 mm²
• Storage and transport temperature, maximum
  +85 °C
• Cable section, maximum
  1 x 2.5 mm²
• Utilisation category AC-15
  3 A
• Standards
  EN 60947-5-1, EN ISO 14119
• Mechanical life, minimum
  1,000,000 Operations
• Terminal Connector
  Screw terminals
Rated impulse withstand voltage Uimp
4 kV
Electrical power consumption, maximum
8.5 W
Required rated short-circuit current to EN 60947-5-1
400 A
Emergency exit
Yes
Number of safety contacts
3
Actuating speed, maximum
0.2 m/s
Degree of protection
IP65 to EN 60529, IP67 to EN 60529
Number of actuating directions
2
Number of auxiliary contacts
1
Positive break force, minimum
40 N
Height of sensor
204 mm
Rated control voltage
24 VDC
Switching principle
Creep circuit element
Latching force, approx.
50 N
Ambient temperature, minimum
-25 °C
Material of the contacts, electrical
Silver
Active principle
electromechanical
Enclosure material
Thermoplastic, Polyamide PA 6 GF
Mounting
Screws
Thermal test current
5 A
Switching frequency
1,000 /h
Storage and transport temperature, minimum
-40 °C
