AV 20RB2X20U Schmersal Electronic Components

Product Details

• Enclosure material
  Glass-fibre reinforced thermoplastic, self-extinguishing
• Height
  80 mm
• Rated insulation voltage Ui
  500 VAC
• Switching element
  NC contact, NO contact
• Material of the contacts, electrical
  Silver
• With fail-safe locking system (Y/N)
  Yes
• Permanent magnet
  Ceramic oxide magnets with high coercive field strength
• Ambient temperature, maximum
  +70 °C
• Manual release
  Yes
• Number of door leafs
  1
• Degree of protection
  IP54
• Thermal test current
  10 A
• Gross weight
  865 g
• Orientation / Alignment
  right-hand model
• X-dimension of the latching bolt
  20 mm
• Utilisation category DC-13
  200 VDC
• Safety functions
  Yes
• Number of safety contacts
  1
• Note (X-dimension of the latching bolt)
  The entire locking bolt length results from the prescribed insertion depth of the locking bolt into the door leaf of 21 mm and dimension X. Dimension X represents the distance between the bottom of the enclosure of the door closing device and the top of t
• Depth
  37 mm
Rated impulse withstand voltage Uimp
6 kV
Number of auxiliary contacts
1
Mounting
rear-side mounting holes
Latching bolt bevelling, bottom
45 °
Switching principle
Slow action
Material of the latching bolt
Brass
Cable entry
without cable gland
Ambient temperature, minimum
-15 °C
Standards
EN 81-20, EN 81-50
Actuating element
Roller lever H65 and bearing block B2
Width
165 mm
Diameter of the latching bolt
18 mm
Utilisation category AC-15
2 A
