D9573K1001Z ROSS Controls Electronic Components
Part#:D9573K1001Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
95 Series 3/2 Single Solenoid Valve, Normally Closed, Ports (In-Out) G1/8", 110/120 VAC
Product Details
- Return Spring
- Media Temperature 41 to 140 F (5 to 60 C)
- Pilot Type Internal
- Exhaust Pipe Size 1/8"
- Duty Rating Continuous Duty
- Valve Body Material Die Cast Aluminum
- Seal Material Buna-N, Viton
- Series 95
- Ambient Temperature 41 to 140 F (5 to 60 C)
- Length 0.7 in (18.0 mm)
- Height (mm) 54.7
- Inlet Pipe Size 1/8"
- Manual Override Non-locking
- Operating Pressure (bar) 1.5 to 10
- Voltage 110/120 VAC
- Width (mm) 91
- Construction Spool
- Ambient Temperature (Celcius) 5 to 60
- Pilot Supply Minimum equal to or greater than inlet pressure
- Height 2.15 in (54.7 mm)
- Application General
- Mounting Inline/Manifold
- Poppet/Spool Material Aluminum
- Power Consumption 3.6 VA holding on 50/60 Hz
- Avg Cv 0.9
- Operating Pressure 22.5 to 150 psig (1.5 to 10 bar)
- Thread Type G
- Outlet Pipe Size 1/8"
- Connection MICRO-MINI EN 175301-803
- Length (mm) 18
- Weight 0.38 lb (0.17 kg)
- Valve Type Directional Control
- Fluid Media Filtered Air
- Function 3/2 Single Solenoid
- Width 3.58 in (91.0 mm)
- Default Position Normally Closed
- Media Temperature (Celcius) 5 to 60
- Actuation Electrical
- Weight (kg) 0.17
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
