PS1E116 Parker Hannifin Industrial Automation Components
Part#:PS1E116
Manufacturer:Parker Hannifin
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
Pneumatic Solenoid Valve - PS1E Series
Product Details
- HTS Code 8481909020
- Power Consumption 1.2W, 1.6VA
- Electrical Connection terminal strip
- Specifications Met n/a
- Number of Ports 3
- Maximum Flow Rate 0.16 Cv
- Operating Temperature -15 to +60 °C
- Nominal Flow Coefficient n/a
- Seal Material Poppet: Polyurethane | Seals: Nitrile (Buna N)
- Mounting Type Stacking
- Valve Type -
- Number of Manifold Outlets n/a
- Pressure Rating 3 to 8.2 bar
- Actuation Type Solenoid Air Operated
- Number of Positions 2
- Port Type Tube Push-In Connections
- Division Electric Motion and Pneumatic Division - Europe
- Lubricant Lubricated or Non-Lubricated air
- Minimum Flow Rate 0.14 Cv
- Body Material Glass Filled Polyamide
- Input Voltage 12 to 48VDC, 120/240VAC
- Fieldbus Protocol n/a
- Override Functionality Non-Locking and Locking Manual Overrides
- Minimum Operating Pressure 40 psig
- Media Air
- Port Size 6mm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PS1E116 on Applied Automation is $74.99. Order now.
About the product
The PS1E series valve is an internal air piloted stacking style with plug-in coils. Available valve functions are 3/2, and 5/2 single and double solenoid. Each valve is individually wired with a separate conductor. Surge suppressors with an indicating LED are available and are mounted between the coil and the valve body. Internal pilot operation means the supply pressure on the #1 port is directed to the end of the valve where the solenoid operator, when actuated, allows the supply pressure to pass, which is then applied to the piston to shift the spool. Markets Miscellaneous Processing Factory Automation Features/Benefits Various manual override Voltages ranges High flow Low power Mobile version Food version Applications Valve piloting Small actuator piloting Blowing
