PS1E311 Parker Hannifin Industrial Automation Components

Name: PS1E311
Brand: Parker Hannifin
Price: 86.7 USD
Availability: BackOrder

Part#:PS1E311

Manufacturer:Parker Hannifin

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Pneumatic Solenoid Valve - PS1E Series

Product Details

HTS Code
8481909020
Media
Air
Division
Electric Motion and Pneumatic Division - Europe
Nominal Flow Coefficient
n/a
Body Material
Glass Filled Polyamide
Port Size
4mm
Minimum Flow Rate
0.14 Cv
Input Voltage
12 to 48VDC, 120/240VAC
Seal Material
Poppet: Polyurethane | Seals: Nitrile (Buna N)
Number of Ports
3
Number of Positions
2
Operating Temperature
-15 to +60 °C
Number of Manifold Outlets
n/a
Override Functionality
Non-Locking and Locking Manual Overrides
Mounting Type
Stacking
Power Consumption
1.2W, 1.6VA
Pressure Rating
3 to 8.2 bar
Minimum Operating Pressure
40 psig
Valve Type
-
Lubricant
Lubricated or Non-Lubricated air

Port Type

Tube Push-In Connections

Maximum Flow Rate

n/a

Electrical Connection

terminal strip

Fieldbus Protocol

n/a

Actuation Type

Solenoid Air Operated

Specifications Met

IP20

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PS1E311 on Applied Automation is $86.70. Order now.

About the product

The PS1E series valve is an internal air piloted stacking style with plug-in coils. Available valve functions are 3/2, and 5/2 single and double solenoid.  Each valve is individually wired with a separate conductor. Surge suppressors with an indicating LED are available and are mounted between the coil and the valve body. Internal pilot operation means the supply pressure on the #1 port is directed to the end of the valve where the solenoid operator, when actuated, allows the supply pressure to pass, which is then applied to the piston to shift the spool.   Markets Miscellaneous Processing Factory Automation Features/Benefits Various manual override Voltages ranges High flow Low power Mobile version Food version Applications Valve piloting Small actuator piloting Blowing
