7999-40741-7640200 Murr Elektronik Cable Assemblies

Product Details

• Weight
  269 g
• Series
  Connector Systems
• Protection
  IP65, IP66K, IP67 inserted and tightened (EN 60529)
• Material (contact surface)
  Au
• Cable weight [g/m]
  62,59 g
• Color/numbering of wires
  br, bk, bl, wh
• Temperature range (fixed)
  -40...+80 °C
• Operating current per contact
  max. 4 A
• Compression gland
  M12 (SW13)
• Outer Ø
  5.9 mm ±5%
• Diameter (core)
  4× 0.75 mm²
• Color (jacket)
  black
• Rated surge voltage
  2.5 kV
• Mounting method
  inserted, tightened
• Cable number
  764
• Material (wire isolation)
  PVC
• Test voltage
  2000 V AC
• No. of poles
  4-/3-pole
• suitable for corrugated tube (internal Ø)
  10 mm
• Cable identification
  764
AWG
similar to AWG 18
chemical resistance
good resistance to oil, gasoline and chemicals
Product article number of manufacturer
7999-40741-7640200
Material group
IEC 60664-1, category I
Standards
DIN EN 61076-2-101 (M12)
Wire isolation
PVC (br, wh, bl, bk)
Shore hardness (wire isolation)
90 ±5 A
Outer-Ø (jacket)
5.9 mm ±5%
Temperature range (mobile)
-20...+80 °C
Locking of ports
Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
Material (gasket)
FKM
Resistor (core)
max. 26 Ω/km (20 °C)
Stranding combination
4 wires twisted
Nominal voltage
300/500 V AC
Bend radius (moving)
10× outer Ø
Operating voltage
max. 250 V AC/DC
Material
PUR
No./diameter of wires
4× 0.75 mm²
Single wire Ø (core)
0.2 mm
Shore hardness (jacket)
85 ±5 A
Cable length
2 m
LED display
no
Material (contact)
Copper alloy
Approval (cable)
UL (AWM-Style 20549/1729)
Wire-Ø incl. isolation
1.8 mm ±5%
Bend radius (fixed)
7.5× outer Ø
Form
40741
Locking material
Zinc die casting, matte nickel plated
Temperature range
-25...+85 °C, depending on cable quality
Construction (core)
24× 0.2 mm (multi-strand wire class 5)
Material (jacket)
PUR
Jacket Color
black
Coding
A-coded
Pollution Degree
3
Material (wire)
Cu wire, bare
Shield
no
Current load capacity
to DIN VDE 0298-4
