GTV-3-P12 Clippard Electronic Components
Part#:GTV-3-P12
Manufacturer:Clippard
Category:Electronic Components
Product Lifecycle:Active
Product description
3-Way Toggle Valve, 3/8" Push-Quick Fittings
Product Details
- Material, Toggle Electroless Nickel-Plated Steel
- Type Standard
- Function 3-Way Normally-Closed
- Port, Outlet 3/8" PQ Fitting
- Operating Temperature Range 32 to 230°F
- Force 9 lb. nominal @ 100 psig (4 kg @ 7 bar)
- Actuation Toggle
- Operating Pressure 150 psig max.
- Flow Rate 1,070 l/min @ 50 psig (3.5 bar); 1,900 l/min @ 100 psig (7 bar)
- Port, Inlet 3/8" PQ Fitting
- Material, Stem Stainless Steel
- Weight 0.2000
- Medium 2-Way: Air, Water or Oil; 3-Way: Air
- Stem Travel 1/8" (3.2 mm)
- Material, Seals Nitrile Std., FKM Optional
- Unit Imperial
- Mount In-Line
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
