118.483.15 Werma Buzzers

Product Details

• Diameter
  70 mm
• Materials
  PC/ABS
• Rated inrush current
  <500mA
• Conforms with CE
  Yes
• Conforms with FCC
  No
• Protection category
  IP33
• Operating voltage
  24V
• Product weight
  88 g
• WEEE
  Yes
• ICAO Certification
  No
• Housing colour
  Grey
• Operating voltage type
  AC/DC
• Protection class
  Protection class 2
• Conforms with CCC
  No
• Conforms with GL
  No
• Height
  80 mm
• Weight with packaging
  114 g
• Audio frequency
  2400 Hz
• EAC certificate available
  Yes
• Working temperature minimum
  0°C
Operating voltage tolerance
+/- 10%
Pollution degree
2
Conforms with AS-I
No
Type of fixing
Wall mounting
Operating voltage frequency
50Hz
Acoustic service life
5,000 h minimum
Conforms with UL
No
Conforms with VdS
No
Connection
Flat plug
Working temperature maximum
+60°C
Rated operational voltage
24 VDC
Rated operational current
20 mA
Volume (max) at 1m distance
90,0 dB (A)
Acoustic signal image
Continuous tone
Conform with ATEX-directive
No
Conforms with IC
No
Conforms with RoHS CN
No
