118.068.15 Werma Buzzers

Product Details

• Materials
  PC/ABS
• Operating voltage frequency
  50Hz
• Acoustic service life
  5,000 h minimum
• EAC certificate available
  Yes
• Height
  49 mm
• Working temperature minimum
  0°C
• Rated operational current
  20 mA
• Conforms with CE
  Yes
• Conforms with GL
  No
• Housing colour
  Grey
• Operating voltage type
  AC/DC
• Pollution degree
  2
• Conforms with UL
  No
• Conforms with RoHS CN
  No
• Protection category
  IP30
• Operating voltage
  24V
• Volume (max) at 1m distance
  90,0 dB (A)
• Conforms with IC
  No
• Type of fixing
  Built-in mounting
• Rated operational voltage
  24 VDC
Acoustic signal image
Continuous tone
Conforms with CCC
No
Connection
Flat plug
Product weight
30 g
Rated inrush current
50 mA
Conforms with FCC
No
Conforms with VdS
No
Diameter
43 mm
Weight with packaging
43 g
Protection class
Protection class 2
Conform with ATEX-directive
No
ICAO Certification
No
Working temperature maximum
+60°C
Operating voltage tolerance
+/- 10%
Audio frequency
2400 Hz
WEEE
Yes
Conforms with AS-I
No
