01536ET3E254T-W22 WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  230/460 V
• Output Rating
  15 HP
• Rated Speed
  3532 rpm
• Flange Type
  Without
• Number of Poles
  2
• Design
  B
• Mounting
  F-1
• Approx. weight³
  260 lb
• Frequency
  60 Hz
• Rated torque
  22.3 ft.lb
• Ambient temperature
  -20°C to +40°C
• Terminal box¹
  Left position
• Rated voltage
  230/460 V
• Insulation Class
  F
• Rotation¹
  Both (CW and CCW)
• Synchronous speed
  3600 rpm
• Slip
  1.89 %
• Output
  15 HP (11 kW)
• Service factor
  1.25
Number of poles
2
Frame
254/6T
Duty Cycle
Cont.(S1)
Standard
NEMA MG-1
Rated current
34.5/17.2 A
LRC
6.7x(Code G)
Enclosure
IC411 - TEFC
Breakdown torque
270 %
Rated speed
3532 rpm
Degree of Protection
IP55
Output rating
15 HP
No load current
10.6/5.30 A
Temperature rise
80 K
L. R. Amperes
231/116 A
Locked rotor torque
220 %
Flange
Without
Moment of inertia (J)
1.26 sq.ft.lb
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Locked rotor time
36s (cold) 20s (hot)
Voltage
230/460//380 V
Noise level²
72.0 dB(A)
