00589EP3PCT215V2F1-W WEG AC Motors

Product Details

• Number of Poles
  45508 Pole
• Voltage
  200 V
• Output Rating
  1.25/5.0 HP
• Rated Speed
  1780 rpm
• Flange Type
  Without
• Frame
  213/5T
• Moment of inertia (J)
  1.56 sq.ft.lb
• Altitude
  1000 m.a.s.l.
• Rated current
  15.1 A
• Temperature rise
  80 K
• Mounting
  F-1
• LRC
  9.9x(Code M)
• Duty Cycle
  Cont.(S1)
• Standard
  NEMA MG-1
• Terminal box¹
  Left position
• Output
  5 HP (3.7 kW)
• Insulation Class
  F
• Noise level²
  61.0 dB(A)
• Number of Poles
  8/4
• Frequency
  60 Hz
Rated torque
14.8 ft.lb
No load current
8.97 A
Degree of Protection
IP55
Enclosure
IC411 - TEFC
Voltage
200 V
Number of poles
8/4
Rated speed
1780 rpm
Breakdown torque
300 %
Ambient temperature
-20°C to +40°C
Synchronous speed
900/1800 rpm
Rated voltage
200 V
Locked rotor time
18s (cold) 10s (hot)
Rotation¹
Both (CW and CCW)
Flange
Without
Slip
1.11 %
Locked rotor torque
220 %
Starting Method
Direct On Line
L. R. Amperes
149 A
Service factor
1.15
Approx. weight³
180 lb
Output rating
1.25/5.0 HP
