ZR 236-11Z-M20 Schmersal Electronic Components

Product Details

• Gross weight
  60 g
• Actuating element
  Roller plunger
• Terminal Connector
  Screw connection
• Ambient temperature, maximum
  +80 °C
• Width of sensor
  30 mm
• Switchover time, maximum
  5.5 ms
• Material of the contacts, electrical
  Silver
• Number of auxiliary contacts
  1
• Housing construction form
  Norm construction design
• Standards
  IEC 60947-5-1, EN ISO 13849-1, BG-GS-ET-15
• Actuator type to DIN EN 50047
  c
• Safety functions
  Yes
• Mechanical life, minimum
  20,000,000 Operations
• Number of safety contacts
  1
• Enclosure material
  Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
• Actuating speed, minimum
  20 mm/min
• Actuating speed, maximum
  1 m/s
• Actuating force, minimum
  9 N
• Positive break force, minimum
  19 N
• Cable section, minimum
  0.75 mm²
Cable section, maximum
2.5 mm²
Note (Actuating speed)
Actuating speed with actuating angle 30° to switch axis
Note (Cable section)
All indications about the cable section are including the conductor ferrules.
Degree of protection
IP65 to EN 60529, IP67 to EN 60529
Height of sensor
84 mm
Length of sensor
30 mm
Ambient temperature, minimum
-30 °C
Rated insulation voltage Ui
250 V
Rated impulse withstand voltage Uimp
6 kV
Thermal test current
10 A
Utilisation category AC-15
4 A
Required rated short-circuit current to EN 60947-5-1
1,000 A
Utilisation category DC-13
24 VDC
Switching element
NO contact, NC contact
Bounce duration, maximum
3 ms
Switching frequency
5,000 /h
Switching principle
Snap switch element
