ZQ 900-04N Schmersal Electronic Components
Part#:ZQ 900-04N
Alt. Part#:101184477
Manufacturer:Schmersal
Category:Electronic Components
Product Lifecycle:Active
Product description
Pull-wire emergency stop switches; 3 cable entries M 20 x 1.5; Metal enclosure; one-side operation / wire up to 75 m long; Release push button; Position indicator; Robust design; Large wiring compartment; Twisting of towing eye not possible; External wate
Product Details
- Length of the wire, maximum 75 m
- Emergency-Stop button Yes
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Switching principle Snap switch element
- Material of the cover Glass-fibre, thermoplastic
- Terminal Connector Screw connection
- Rated insulation voltage Ui 500 V
- Utilisation category AC-15 4 A
- Standards IEC/EN 60947-5-1, EN ISO 13850, IEC/EN 60947-5-5
- Cable section, minimum 0.75 mm²
- Height of the Sensor, minimum 220.3 mm
- Thermal test current 6 A
- Enclosure coating material painted
- Mechanical life, minimum 1,000,000 Operations
- Height of the Sensor, maximum 236.3 mm
- Rated impulse withstand voltage Uimp 6 kV
- Gross weight 1,275 g
- Length of sensor 97.2 mm
- Degree of protection IP65 to EN 60529
- Utilisation category DC-13 1 A
- Enclosure material Zinc die-cast
- Cable section, maximum 2.5 mm²
- Ambient temperature, maximum +70 °C
- Indicator lamp No
- Number of safety contacts 4
- Ambient temperature, minimum -25 °C
- Switching element Opener (NC)
- Material of the contacts, electrical Silver
- Width of sensor 71.5 mm
- Relative humidity, maximum 95 %
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
