Z4VH 335-11Z-M20 Schmersal Electronic Components

Product Details

• Gross weight
  265 g
• Actuating speed, maximum
  2.5 m/s
• Cable section, maximum
  2.5 mm²
• Rated impulse withstand voltage Uimp
  6 kV
• Switchover time, maximum
  2 ms
• Number of auxiliary contacts
  1
• Material of the contacts, electrical
  Silver
• Width of sensor
  40.5 mm
• Required rated short-circuit current to EN 60947-5-1
  1,000 A
• Switching element
  NO contact, NC contact
• Safety functions
  Yes
• Enclosure material
  Light alloy die-casting
• Terminal Connector
  Screw connection
• Degree of protection
  IP65 to EN 60529, IP67 to EN 60529
• Ambient temperature, minimum
  -30 °C
• Roller material
  Plastic
• Note (Actuating speed)
  Actuating speed with actuating angle 30° to switch axis
• Cable section, minimum
  0.75 mm²
• Rated insulation voltage Ui
  250 V
• Switching frequency
  5,000 /h
Housing construction form
Norm construction design
Note Bounce duration
Bounce duration in accordance with actuating speed
Actuating torque, minimum
0.3 Nm
Ambient temperature, maximum
+80 °C
Number of safety contacts
1
Lever material
Metal film
Length of sensor
60.6 mm
Utilisation category AC-15
4 A
Enclosure coating material
painted
Actuating element
Roller lever
Note (Cable section)
All indications about the cable section are including the conductor ferrules.
Thermal test current
10 A
Switching principle
Snap switch element
Actuator type to DIN EN 50041
A
Mechanical life, minimum
30,000,000 Operations
Height of sensor
134 mm
Utilisation category DC-13
24 VDC
