TR 335-11Z-M20 Schmersal Electronic Components

Product Details

• Number of safety contacts
  1
• Actuating speed, maximum
  0.5 m/s
• Width of sensor
  40.5 mm
• Utilisation category AC-15
  230 VAC
• Actuator type to DIN EN 50041
  C
• Length of sensor
  38 mm
• Ambient temperature, minimum
  -30 °C
• Switching frequency
  5,000 /h
• Gross weight
  185 g
• Actuating force, minimum
  17 N
• Note (Cable section)
  All indications about the cable section are including the conductor ferrules.
• Rated insulation voltage Ui
  500 V
• Switching element
  NO contact, NC contact
• Enclosure coating material
  painted
• Actuating element
  Roller plunger
• Note (Switchover time)
  Switchover time in accordance with actuating speed
• Rated impulse withstand voltage Uimp
  6 kV
• Housing construction form
  Norm construction design
• Number of auxiliary contacts
  1
• Cable section, maximum
  2.5 mm²
Ambient temperature, maximum
+80 °C
Safety functions
Yes
Mechanical life, minimum
30,000,000 Operations
Cable section, minimum
0.75 mm²
Required rated short-circuit current to EN 60947-5-1
1,000 A
Enclosure material
Light alloy die-casting
Terminal Connector
Screw connection
Degree of protection
IP65 to EN 60529, IP67 to EN 60529
Material of the contacts, electrical
Silver
Note (Actuating speed)
Actuating speed with actuating angle 30° to switch axis
Height of sensor
116.6 mm
Thermal test current
10 A
Switching principle
Slow action
Bounce duration, maximum
2 ms
Utilisation category DC-13
4 A
