TR 335-03Z Schmersal Electronic Components

Product Details

• Bounce duration, maximum
  2 ms
• Actuator type to DIN EN 50041
  C
• Terminal Connector
  Screw connection
• Thermal test current
  10 A
• Number of safety contacts
  3
• Actuating speed, maximum
  0.5 m/s
• Degree of protection
  IP65 to EN 60529, IP67 to EN 60529
• Utilisation category DC-13
  4 A
• Gross weight
  190 g
• Actuating force, minimum
  17 N
• Cable section, minimum
  0.75 mm²
• Rated insulation voltage Ui
  250 V
• Housing construction form
  Norm construction design
• Note (Cable section)
  All indications about the cable section are including the conductor ferrules.
• Ambient temperature, minimum
  -30 °C
• Utilisation category AC-15
  4 A
• Actuating element
  Roller plunger
• Note (Actuating speed)
  Actuating speed with actuating angle 30° to switch axis
• Width of sensor
  40.5 mm
• Material of the contacts, electrical
  Silver
Note (Switchover time)
Switchover time in accordance with actuating speed
Height of sensor
116.6 mm
Required rated short-circuit current to EN 60947-5-1
1,000 A
Switching principle
Slow action
Ambient temperature, maximum
+80 °C
Enclosure coating material
painted
Mechanical life, minimum
30,000,000 Operations
Switching element
Opener (NC)
Safety functions
Yes
Enclosure material
Light alloy die-casting
Length of sensor
38 mm
Cable section, maximum
2.5 mm²
Rated impulse withstand voltage Uimp
4 kV
Switching frequency
5,000 /h
