TESK-LU-11L1-3M Schmersal Safety Switches
Part#:TESK-LU-11L1-3M
Alt. Part#:103005732
Manufacturer:Schmersal
Category:Safety Switches
Product Lifecycle:Active
Product description
TESK-LU-11L1-3M Schmersal - Safety switch for hinged guards; Hinge safety switch; cable bottom; adjustable switching angle; long hinge part; Metal enclosure
Product Details
- Adjustable switching angle Yes
- Terminal Connector cable
- Rated insulation voltage Ui 60 V
- Enclosure material Zinc die-cast
- Cable section, maximum 1 mm²
- Width of sensor 98 mm
- Utilisation category DC-13 1 A
- Colour of the housing Silver
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Ambient temperature, minimum -25 °C
- Alignment aid Yes
- Cable section, minimum 0.5 mm²
- Height of sensor 116 mm
- Utilisation category AC-15 2 A
- Gross weight 508 g
- Material of the contacts, electrical Silver-nickel alloy 10
- Number of safety contacts 1
- Degree of protection IP65
- Mechanical life, minimum 1,000,000 Operations
- Mounting outside Yes
- Number of auxiliary contacts 1
- Length of sensor 20 mm
- Ambient temperature, maximum +65 °C
- Thermal test current 2.5 A
- Switching frequency 1,200 /h
- Switching principle Creep circuit element
- Mounting inside Yes
- Length of cable 3 m
- Rated impulse withstand voltage Uimp 0.8 kV
- Switching element NO contact, NC contact
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TESK-LU-11L1-3M on Applied Automation is $309.00. Order now.
