NAS 311 ST1-AS Schmersal Electronic Components

Product Details

• AS-i Input, Channel 2
  Data bits DI 2 / DI 3 = dynamic code transmission
• Gross weight
  330 g
• Storage and transport temperature, maximum
  +85 °C
• AS-i, IO-Code
  0x7
• AS-i Input module address
  0
• Terminal Connector
  Connector plug M12, 4-pole, (A-coding)
• Ambient temperature, minimum
  -25 °C
• AS-i, ID-Code
  0xB
• Enclosure material
  Plastic
• Relative humidity, maximum
  95 %
• Operating Current
  50 mA
• AS-i Input, Channel 1
  Data bits DI 0 / DI 1 = dynamic code transmission
• Width of sensor
  85 mm
• AS-i Operating voltage, minimum
  26.5 VDC
• Note (AS-i Operating voltage)
  Protection against polarity reversal
• AS-i Outputs, DO 0 … DO 3
  No Function
• Degree of protection
  IP65 to EN 60529
• Ambient temperature, maximum
  +60 °C
• AS-i Version
  V 2.1
• Note (AS-i Input module address)
  Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
Standards
IEC 61508, EN 60947-5-1, EN ISO 13850
Length of sensor
97.8 mm
Relative humidity, minimum
30 %
AS-i, ID-Code2
0xE
Connector position
Bottom
Storage and transport temperature, minimum
-25 °C
AS-i Operating voltage AS-i maximum
31.6 VDC
AS-i, ID-Code1
0xF
Height of sensor
85 mm
Note (Relative humidity)
non-condensing, non-icing
AS-i Profile
S-7.B.0.E
AS-i Parameter bits, P0 ... P3
No function
