MAF/S 441-11Y Schmersal Electronic Components
Part#:MAF/S 441-11Y
Alt. Part#:103006789
Manufacturer:Schmersal
Category:Electronic Components
Product Lifecycle:Active
Product description
Position switch; Medium-duty position switches; Level switch for silos and storage containers; Aluminium enlosure, Detection cone; Can be actuated from any direction; Disabling at 30° deflection or in case of pressure from the bottom; 1 Normally open cont
Product Details
- Active principle mechanical
- Actuating speed, maximum 1 m/s
- Diameter of the Detection cone 90 mm
- Standards EN 60947-5-1
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Rated impulse withstand voltage Uimp 4 kV
- Bounce duration, maximum 5 ms
- Material of the Detection cone Plastic
- Actuating speed, minimum 1 mm/min
- Cable section, minimum 1.5 mm²
- Ambient temperature, minimum -30 °C
- Note (Switching element) galvanically separated contact bridges
- Gross weight 1,460 g
- Actuating element Detection cone
- Cable section, maximum 2.5 mm²
- Ambient temperature, maximum +90 °C
- Switching principle Snap switch element
- Number of openers 1
- Terminal Connector Screw connection
- Height of sensor 438 mm
- Switching element NO contact, NC contact
- Mechanical life, minimum 1,000,000 Operations
- Thermal test current 16 A
- Number of shutters 1
- Actuating force 14 N
- Length of sensor 61 mm
- Rated insulation voltage Ui 250 V
- Switchover time, maximum 35 ms
- Enclosure coating material painted
- Material of the contacts, electrical Silver
- Degree of protection IP65 to EN 60529
- Utilisation category AC-15 250 VAC
- Enclosure material Aluminium
- Width of sensor 106 mm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
