EF10.2 Schmersal Safety Accessories

Product Details

• Material of the contacts, electrical
  Silver
• Mounting flange position
  2
• Width
  10 mm
• Resistant to vibration
  Resistance to vibration: 20 g / 10…200 Hz
• Bounce duration, maximum
  5 ms
• Standards
  EN 60947-5-1, IEC/EN 60947-1
• Contact opening
  1 mm
• Cable section, maximum
  2.5 mm², rigid, 1.5 mm², flexible
• Degree of protection of clips or terminals
  IP20
• Utilisation category AC-15
  230 VAC
• Switching principle
  Slow action
• Installation instructions
  pluggable
• Terminal Connector
  Screw connection
• Contact labelling
  21-22
• Degree of protection of the switch rooms
  IP40
• Thermal test current
  10 A
• Suitable for low-voltages
  ≥ 5 V / ≥ 3.2 mA
• Note Bounce duration
  Bounce duration at an Actuating speed of 100mm/s
• Mechanical life, minimum
  10,000,000 Operations
• Cable section, minimum
  0.5 mm², rigid, 0.5 mm², flexible
Ambient temperature, maximum
+80 °C
Switching frequency
1,200 /h
Utilisation category DC-13
5 A
Enclosure material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
Gross weight
35 g
Length
46 mm
Depth
60 mm
Restistance to shock
110 g / 4 ms
positive break travel
2 mm
Number of openers
1
Note (Cable section)
All indications about the cable section are including the conductor ferrules.
Ambient temperature, minimum
-25 °C
Rated insulation voltage Ui
400 V
Switching element
Opener (NC)
