BNS 36 STG-AS-R Schmersal Electronic Components

Product Details

• Installation conditions (mechanical)
  quasi-flush
• Repeat accuracy R
  ≤ 0.1 x Sao
• Coding
  Yes
• Notice (Switch distance Sn)
  Axial misalignment, a horizontal and vertical misalignment of the safety sensor and the actuator are tolerated. The possible misalignment depends on the distance of the active surfaces of the sensor and the actuator. The sensor remains active within the t
• Gross weight
  110 g
• Storage and transport temperature, maximum
  +70 °C
• Ambient temperature, minimum
  -25 °C
• Degree of pollution to VDE 0100
  3
• Door hinge
  Right
• Wire cross-section
  0.23 mm2
• Overvoltage category
  III
• AS-i, IO-Code
  0x0
• AS-i Input module address
  0
• Reaction time, maximum
  100 ms
• Ambient temperature, maximum
  +60 °C
• Note (AS-i Operating voltage)
  Protection against polarity reversal
• AS-i, ID-Code
  0xB
• Active principle
  Magnetic drive
• Ensured switch distance ON Sao
  7 mm
• AS-i Operating voltage, minimum
  18 VDC
AS-i Profile
S-0.B.F.E
AS-i Outputs, DO 0 … DO 3
No Function
Actuating element
Magnet
Enclosure material
Glass-fibre, reinforced thermoplastic
Storage and transport temperature, minimum
-25 °C
AS-i, ID-Code2
0xE
Standards
IEC 61508, IEC 60947-5-3, EN 62026-2
Length of sensor
13 mm
Rated impulse withstand voltage Uimp
0.8 kV
AS-i Specification
Safety-Slave
AS-i Input, Channel 2
Data bits DI 2 / DI 3 = dynamic code transmission
Length of cable
2 m
Height of sensor
25 mm
AS-i Operating voltage AS-i maximum
31.6 VDC
AS-i Version
V 2.1
AS-i Parameter bits, P0 ... P3
No function
Integral System Diagnostics, status
Yes
Direction of motion
Head-on to the active surface
Terminal Connector
Connecting cable with M12 connector, straight, 4-pole
Material of the Cable mantle
LSYY
Degree of protection
IP67 to EN 60529
Restistance to shock
30 g / 11 ms
Rated insulation voltage Ui
32 VDC
AS-i, ID-Code1
0xF
Note (AS-i Parameter bits)
Set the parameter outputs to "1111" (0xF)
Note (AS-i Input module address)
Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
Ensured switch distance OFF Sar
17 mm
Resistance to vibrations to EN 60068-2-6
10 … 55 Hz, amplitude 1 mm
AS-i Current consumption, maximum
50 mA
AS-i Input, Channel 1
Data bits DI 0 / DI 1 = dynamic code transmission
