BNS 260-02/01Z-R 5,0M Schmersal Electronic Components

Product Details

• Coding level according to ISO 14119
  Low
• Wire cross-section
  0.25 mm2
• Standards
  IEC 60947-5-3, BG-GS-ET-14
• Number of cable wires
  6
• Length of sensor
  13 mm
• Switching current, maximum
  0.4 A
• Number of safety contacts
  2
• Ensured switch distance ON Sao
  5 mm
• Width of sensor
  26 mm
• Resistance to vibrations to EN 60068-2-6
  10 … 55 Hz, amplitude 1 mm
• Number of shutters
  3
• Length of cable
  5 m
• Ambient temperature, maximum
  +70 °C
• Switching capacity, maximum
  10 VA
• Gross weight
  0.3 g
• Terminal Connector
  Cable
• Storage and transport temperature, maximum
  +70 °C
• Number of openers
  0
• Actuating element
  Magnet
• Material of the Cable mantle
  PVC
Storage and transport temperature, minimum
-25 °C
Enclosure material
Glass-fibre, reinforced thermoplastic
Ensured switch distance OFF Sar
15 mm
Height of sensor
36 mm
Restistance to shock
30 g / 11 ms
Active principle
Magnetic drive
Direction of motion
Head-on to the active surface
Ambient temperature, minimum
-25 °C
Installation conditions (mechanical)
quasi-flush
Notice (Switch distance Sn)
Axial misalignment, a horizontal and vertical misalignment of the safety sensor and the actuator are tolerated. The possible misalignment depends on the distance of the active surfaces of the sensor and the actuator. The sensor remains active within the t
Degree of protection
IP67
Switching frequency, maximum
5 Hz
