A-K6P-M8-R-W-2M-GY-1-X-A-4 Schmersal Cable Assemblies
Part#:A-K6P-M8-R-W-2M-GY-1-X-A-4
Alt. Part#:101206013
Manufacturer:Schmersal
Category:Cable Assemblies
Product Lifecycle:Active
Product description
A-K6P-M8-R-W-2M-GY-1-X-A-4 Schmersal - Safety sensors; Magnetic safety sensors; M8, round 8 mm; Pre-wired cable; 6-pole; Latching interlocking
Product Details
- Colour of the handle Black
- Ambient temperature, maximum (Connector) +90 °C
- Wire cross-section 0.14 mm2
- Design angled
- Temperature (fixed), maximum +80 °C
- Length of cable 2 m
- Material of the gland Plastic, TPU
- Rated operating voltage 30 V
- Operating current 1,500 mA
- Number of cable wires 6
- Connector typ Female connector, M8
- Material of the handle Plastic, TPU
- Temperature (repeated), maximum +80 °C
- Gross weight 65 g
- Connector latching Latching interlocking
- Thermal test current 1.5 A
- Number of poles 6
- Bending radius (fixed) 5 x Ø-cable
- Degree of protection IP65, IP67, IP69
- Temperature (repeated), minimum -5 °C
- Bending radius (repeated) 10 x Ø-cable
- Material of the Cable mantle PVC
- Temperature (fixed), minimum -40 °C
- Cable diameter 4.9 mm
- Colour of the Cable mantle Grey
- Ambient temperature, minimum (Connector) -30 °C
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of A-K6P-M8-R-W-2M-GY-1-X-A-4 on Applied Automation is $62.00. Order now.
