CP20NB07101Z ROSS Controls Electronic Components
Part#:CP20NB07101Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
CP Series 2/2 Solenoid Valve, Normally Open, Port (In) 2-1/2" NPT, Port (Out) 2-1/2" NPT, 110/120 VAC
Product Details
- Outlet Pipe Size 2-1/2"
- Media Temperature 40 to 175 F (4 to 80 C)
- Operating Pressure (bar) vacuum to 10
- Default Position Normally Open
- Inlet Pipe Size 2-1/2"
- Ambient Temperature (Celsius) 4 to 50
- Weight (kg) 8.9
- Thread Type NPT
- Series CP
- Mounting Base Mounted
- Power Consumption 5.8 watts nominal, 6.5 watts maximum
- Height (mm 268.9
- Height 10.59 in (268.9 mm)
- Construction Poppet
- Pilot Type Internal/External
- Length (mm 171.5
- Width (mm) 150.4
- Actuation Electrical
- Length 6.75 in (171.5 mm)
- Poppet/Spool Material Acetal & Stainless Steel
- Application General
- Duty Rating Continuous Duty
- Media Temperature (Celsius) 4 to 80
- Valve Body Material Cast Aluminum
- Return Spring Assisted Air
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Weight 19.5 lb (8.9 kg)
- Function 2/2 Single Solenoid
- Avg Cv 108
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Width 5.92 in (150.4 mm)
- Valve Type Directional Control
- Manual Override Locking
- Pilot Supply Minimum equal to or greater than inlet pressure
- Seal Material Buna-N
- Connection EN 175301-803 Form A
- Fluid Media Filtered Air
- Voltage 110/120 VAC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
