2174B7002Z ROSS Controls Electronic Components
Part#:2174B7002Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
21 Series Low Temp 3/2 Single Solenoid Valve, Normally Open, 1-1/4" NPT (In-Out), 1-1/2" NPT (Exhaust), 110/120 VAC
Product Details
- Height (mm) 271
- Cv (2-3) 23.0
- Weight (kg) 3.4
- Weight 7.5 lb (3.4 kg)
- Height 10.57 in (271 mm)
- Outlet Pipe Size 1-1/4"
- Function 3/2 Single Solenoid
- Cv (1-2) 21.0
- Inlet Pipe Size 1-1/4"
- Width (mm) 104
- Width 4.09 in (104 mm)
- Length (mm) 168
- Exhaust Pipe Size 1-1/2"
- Size 1-1/4
- Length 6.63 in (168 mm)
- Media Temperature -40 to 175 F (-40 to 80 C)
- Ambient Temperature (Celsius) -40 to 50
- Media Temperature (Celsius) -40 to 80
- Voltage 110/120 VAC
- Ambient Temperature -40 to 120 F (-40 to 50 C)
- Default Position Normally Open
- Actuation Electrical
- Application Low Temperature
- Poppet/Spool Material Aluminum and Stainless Steel
- Valve Body Material Cast Aluminum
- Seal Material Fluorocarbon
- Operating Pressure 30 to 150 psig (2 to 10 bar)
- Operating Pressure (bar) 2 to 10
- Pilot Supply Minimum Equal to or greater than inlet pressure
- Construction Poppet
- Series 21
- Thread Type NPT
- Valve Type Directional Control
- Duty Rating Continuous Duty
- Pilot Type External
- Fluid Media Filtered air
- Return Spring
- Mounting Inline
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
