2174B6012Z ROSS Controls Electronic Components
Part#:2174B6012Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
21 Series Low Temp 3/2 Single Solenoid Valve, Normally Open, 1" NPT (In-Out), 1" NPT (Exhaust), 110/120 VAC
Product Details
- Mounting Inline
- Operating Pressure (bar) 2 to 10
- Function 3/2 Single Solenoid
- Weight 3.3 lb (1.5 kg)
- Series 21
- Actuation Electrical
- Width 3.03 in (77 mm)
- Fluid Media Filtered air
- Application Low Temperature
- Ambient Temperature (Celsius) -40 to 50
- Cv (1-2) 7.7
- Construction Poppet
- Seal Material Fluorocarbon
- Media Temperature -40 to 175 F (-40 to 80 C)
- Width (mm) 77
- Return Spring
- Valve Body Material Cast Aluminum
- Voltage 110/120 VAC
- Length (mm) 114
- Duty Rating Continuous Duty
- Poppet/Spool Material Aluminum and Stainless Steel
- Media Temperature (Celsius) -40 to 80
- Length 4.48 in (114 mm)
- Valve Type Directional Control
- Exhaust Pipe Size 1"
- Weight (kg) 1.5
- Operating Pressure 30 to 150 psig (2 to 10 bar)
- Size 3/4
- Outlet Pipe Size 1"
- Height (mm) 206
- Thread Type NPT
- Default Position Normally Open
- Inlet Pipe Size 1"
- Cv (2-3) 7.6
- Pilot Type External
- Pilot Supply Minimum Equal to or greater than inlet pressure
- Ambient Temperature -40 to 120 F (-40 to 50 C)
- Height 8.1 in (206 mm)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2174B6012Z on Applied Automation is $413.25. Order now.
