2171B6002Z ROSS Controls Electronic Components
Part#:2171B6002Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
21 Series Low Temp 2/2 Single Solenoid Valve, Normally Closed, 1" NPT (In-Out), 110/120 VAC
Product Details
- Avg Cv 24.0
- Weight 7.5 lb (3.4 kg)
- Weight (kg) 3.4
- Height 10.54 in (267 mm)
- Height (mm) 267
- Outlet Pipe Size 1"
- Length (mm) 165
- Length 6.49 in (165 mm)
- Function 2/2 Single Solenoid
- Inlet Pipe Size 1"
- Size 1-1/4
- Width 4.09 in (104 mm)
- Width (mm) 104
- Media Temperature (Celsius) -40 to 80
- Ambient Temperature -40 to 120 F (-40 to 50 C)
- Media Temperature -40 to 175 F (-40 to 80 C)
- Ambient Temperature (Celsius) -40 to 50
- Voltage 110/120 VAC
- Pilot Type Internal/External
- Actuation Electrical
- Poppet/Spool Material Aluminum and Stainless Steel
- Pilot Supply Minimum Equal to or greater than inlet pressure
- Application Low Temperature
- Valve Body Material Cast Aluminum
- Seal Material Fluorocarbon
- Operating Pressure (bar) 2 to 10
- Operating Pressure 30 to 150 psig (2 to 10 bar)
- Fluid Media Filtered air
- Duty Rating Continuous Duty
- Power Consumption 87 VA inrush, 30 VA holding on 50/60 Hz
- Construction Poppet
- Return Spring
- Manual Override Non-locking
- Connection Hardwired
- Series 21
- Valve Type Directional Control
- Thread Type NPT
- Mounting Inline
- Default Position Normally Closed
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
