2171B5001Z ROSS Controls Electronic Components
Part#:2171B5001Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
21 Series High Temp 2/2 Single Solenoid Valve, Normally Closed, 3/4" NPT (In-Out), 110/120 VAC
Product Details
- Return Spring
- Manual Override Non-locking
- Seal Material Fluorocarbon
- Width 3.15 in (18 mm)
- Application High Temperature
- Media Temperature 0 to 300 F (-17 to 150 C)
- Actuation Electrical
- Avg Cv 9.0
- Thread Type NPT
- Operating Pressure (bar) 2 to 10
- Pilot Type Internal/External
- Height (mm) 198
- Valve Type Directional Control
- Fluid Media Filtered air
- Size 3/4
- Inlet Pipe Size 3/4"
- Mounting Inline
- Ambient Temperature (Celsius) -17 to 122
- Ambient Temperature 0 to 250 F (-17 to 122 C)
- Length 4.45 in (113 mm)
- Operating Pressure 30 to 150 psig (2 to 10 bar)
- Duty Rating Continuous Duty
- Outlet Pipe Size 3/4"
- Weight 3.3 lb (1.5 kg)
- Default Position Normally Closed
- Valve Body Material Cast Aluminum
- Poppet/Spool Material Aluminum and Stainless Steel
- Width (mm) 18
- Series 21
- Pilot Supply Minimum Equal to or greater than inlet pressure
- Voltage 110/120 VAC
- Height 7.8 in (198 mm)
- Connection Hardwired
- Power Consumption 87 VA inrush, 30 VA holding on 50/60 Hz
- Length (mm) 113
- Construction Poppet
- Media Temperature (Celsius) -17 to 150
- Function 2/2 Single Solenoid
- Weight (kg) 1.5
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
