PAXD0110 Red Lion Industrial Automation Components

PAXD0110 on Applied Automation
Red Lion

Part#:PAXD0110

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAXD0110 is a digital meter designed for DC universal analog measurements. It features three user inputs and a single analog output for retransmission, housed in a 1/8 DIN (96x48mm) form factor with 14.2mm green digits for clear display. The meter supports a wide range of supply voltages from 85-250Vac, including specific values such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. It belongs to the PAX series and offers dimensions of 1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95"). The PAXD0110 is equipped with an IP65 NEMA 4X degree of protection, ensuring durability in various environments. It has a 20Hz analog input sampling rate and accommodates one analog input with a wide range of measurements (-200...+200μA / -2...+2mA / -20...+20mA / -200...+200mA / -2...+2A / -200...+200V / -2...+2V / -20...+20V / -300...+300V / 100Ω / 1kΩ / 10kΩ DC; 16-bits conversion). Additionally, it includes three digital inputs (Sink/Source) for user input functionality.

Product Details

  • Main function
    Meter (Digital)
  • Analog inputs
    1 x analog input (-200...+200μA / -2...+2mA / -20...+20mA / -200...+200mA / -2...+2A / -200...+200V / -2...+2V / -20...+20V / -300...+300V / 100Ω / 1kΩ / 10kΩ DC; 16-bits conversion)
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
  • Product series / family name
    Process indicators
  • Digital inputs
    3 x digital inputs (Sink/Source) (USER INPUT)
  • Design
    3 user inputs 1/8 DIN (96x48mm) 14.2mm green digits communication capability
  • Primary brand
    Red Lion
  • Supply voltage (DC)
    11-36Vdc (12Vdc / 24Vdc)
  • Sub-range name
    PAX series
  • Analog outputs
    1 x analog output (retransmission)
  • Functions
    DC universal analog meter
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
  • Display
    1 row x 6-digits green characters (14.2mm / 0.56" high) LED display
  • Degree of protection
    IP65 NEMA 4X
  • Frequency
    20Hz analog input sampling rate
  • Order code / Manufacturer SKU
    PAXD0110

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PAXD0110 on Applied Automation is $476.00. Order now.

PAXD0110 Related Documents

Red Lion - PAX ANALOG - Product Manual.pdf

Manufacturer warranty

PAXD0110 Red Lion
