50140 Murr Elektronik Control Circuits
Part#:50140
Alt. Part#:6650140
Manufacturer:Murr Elektronik
Category:Control Circuits
Product Lifecycle:Active
Product description
50140 Murrelektronik - DC-MOTOR COMMUTATING CIRCUIT, IN: 24 VDC - OUT: 24 VDC / 3 A, 12,4 mm screw-type terminal
Product Details
- Weight 60 g
- Series Interface Modules
- Temperature range 0...+50 °C
- Voltage range OFF 0...5 V DC
- Dimensions H×W×D 90×12.4×70 mm
- Changing time max. 50 ms
- Test isolation voltage no galvanic separation
- Input current 10 mA
- Housing Black plastic, flame retardant
- Voltage range ON 15...30 V DC
- LED display LED (red): error (over current/over heated)
- Switching voltage 19.2...30 V DC
- Product article number of manufacturer 50140
- Leakage current (output is open) max. 10 mA
- Mounting method DIN-rail mountable TH35 or G32 (EN 60715)
- Highest current approx. 6 A for 100 ms
- Saturation voltage (across output) max. 1.4 V DC
- Switching frequency max. 1 Hz (motor dependant)
- Switching time ON/OFF 1.2/10 ms
- Switching current per output max. 3 A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 50140 on Applied Automation is $273.00. Order now.
