7999-08041-6331500 Murr Elektronik Cable Assemblies

Product Details

• Weight
  461 g
• Series
  Connector Systems
• Operating voltage
  max. 50 V AC/60 V DC
• Form
  08041
• Material (wire)
  Cu wire, bare
• Single wire Ø (core)
  0.1 mm
• Shield
  no
• Temperature range (fixed)
  -40...+80 °C, (+90 °C at max. 10 000 operating hours)
• Bend radius (moving)
  10× outer Ø
• Protection
  IP67 inserted and tightened (EN 60529)
• suitable for corrugated tube (internal Ø)
  6.5 mm
• AWG
  similar to AWG 22
• Color/numbering of wires
  br, bk, bl
• Current load capacity
  to DIN VDE 0298-4
• Acceleration (C-track)
  max. 10 m/s²
• Compression gland
  M8 (SW9)
• Approval (cable)
  cURus (AWM-Style 20549/10493); CE conform
• Shore hardness (jacket)
  90 ±5 A
• No. of bending cycles (C-track)
  max. 10 Mio. (25 °C)
• Cable length
  15 m
Material group
IEC 60664-1, category I
Cable Type
3 (PUR)
Material property (jacket)
CFC-, halogen-, cadmium-, silicone- and lead-free, matt, low-adhesion, machine easy to process, abrasion-resistant, hydrolysis and microbial resistant
Test voltage
2500 V AC
Torsion stress
±180°/m
Operating current per contact
max. 4 A
Standards
DIN EN 61076-2-104 (M8)
Locking material
Zinc die casting, nickel-plated
Wire-Ø incl. isolation
1.25 mm ±5%
Outer-Ø (jacket)
4.1 mm ±5%
Bend radius (fixed)
5× outer Ø
Locking of ports
Screw thread (M8×1 mm) recommended torque 0.4 Nm, self-securing
Diameter (core)
3× 0.34 mm²
Shore hardness (wire isolation)
70 ±5 D
Nominal voltage
300 V AC
Travel speed (C-track)
max. 3 m/s
Material
PUR
Cable identification
633
Material property (wire isolation)
CFC-, halogen-, cadmium-, silicone- and lead-free
chemical resistance
good resistance to oil, gasoline and chemicals (EN 60811-404)
No. of torsion cycles
max. 2 Mio. (25 °C)
Rated surge voltage
1.5 kV
Construction (core)
42× 0.1 mm (multi-strand wire class 6)
Material (jacket)
PUR
Temperature range (mobile)
-25...+80 °C, (+90 °C at max. 10 000 operating hours)
Product article number of manufacturer
7999-08041-6331500
Temperature range
-25...+85 °C, depending on cable quality
Resistor (core)
max. 57 Ω/km (20 °C)
Material (wire isolation)
PP
thermal resistance
flame retardand UL 1581 Section 1090 (H), CSA FT2 / IEC 60332-2-2
Operating voltage (only UL listed)
30 V AC/DC
Pollution Degree
3
Cable weight [g/m]
29,7 g
Stranding combination
3 wires twisted
Color (jacket)
black
Torsion speed
35 cycles/min
