55075 Murr Elektronik I/O Systems

Product Details

• Weight
  420 g
• Series
  Field Bus System
• Fieldbus
  CAN 1 Mbit/s; M12, A-coded
• Communication status
  via LED
• Protection
  IP67
• Sensor supply US
  24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected
• Addressing
  Rotary switch 1...99
• Sensor-system/actuator supply
  7/8", 5-pole, 2× max. 9 A
• Diagnostic via BUS
  per module
• Type
  for 3-wire sensors or mechanical switches, PNP
• Mounting method
  2-hole screw mounting, compatible with I/O modules of MVK model range
• Monitoring - no voltage
  yes
• I/O ports
  M12, 5-pole, A-coded
• Diagnostic via LED
  per module and channel
• Dimensions H×W×D
  39×63×225 mm
• Product article number of manufacturer
  55075
• Temperature range
  -25...+70 °C (storage temperature -25...+70 °C)
• Monitoring - under voltage
  yes
